# 🚨 _One-Stop-Shop_ Sovol SV06 Klipper Configuration This branch contains the Klipper configuration and firmware for the **Sovol SV06 Plus** 3D printer. For the **Sovol SV06**, please refer to the [master](https://github.com/bassamanator/Sovol-SV06-firmware/tree/master) branch. To use the One-Stop-Shop Klipper Configuration with a _different printer_, please switch to the [any-printer](https://github.com/bassamanator/Sovol-SV06-firmware/tree/any-printer) branch. I am creating these files for my personal use and cannot be held responsible for what it might do to your printer. Use at your own risk. 🙏🏻 🙌🏻 Big thanks to [blanchas3d](https://github.com/blanchas3d) in testing out this branch and reporting issues. # Highlights - 💥 This Klipper configuration is an _endpoint_, meaning that it contains **everything** that you could possibly need in order to have an excellent Klipper experience! 💥 - `NEW` Filament runout sensor usage implemented. - Minimum configuration settings for Mainsail/Fluiddpi to work. - SuperSlicer config bundle that contains the printer configuration, as well as what are considered by many to be the best print settings available for any FDM printer ([Ellis' SuperSlicer Profiles](https://github.com/AndrewEllis93/Ellis-SuperSlicer-Profiles)). Find the differences between the different print setting profiles [here](https://github.com/AndrewEllis93/Ellis-SuperSlicer-Profiles/tree/master/SuperSlicer). But basically, the 45 degree profile places the seam at the back. - Bed model and texture to use in SuperSlicer/PrusaSlicer. - Macros - **Improved** mechanical gantry calibration/`G34` macro that provides the user audio feedback, and time to check the calibration. - Misc macros: `PRINT_START`, `CANCEL_PRINT`, `PRINT_END`, `PAUSE`, `RESUME`. - Parking macros (parks the printhead at various locations): `PARKFRONT`, `PARKFRONTLOW`, `PARKREAR`, `PARKCENTER`, `PARKBED`. - Load/unload filament macros. - Purge line macro. ## Stay Up-to-Date I work on this repository all the time and a lot of new features are coming. Watch releases of this repository to be notified for future updates: Raspberry Pi # Preface Although I've made switching over to Klipper as easy as is possible, it can still be a challenge for some, especially considering that most of you have likely never used GNU+Linux. Save yourself the frustration, and fully read all documentation found on this page. Also note that Klipper is not a _must_, and is not for everyone. You can stick with Marlin, and have a fine 3D printing experience. # Installation Steps ## Before You Begin - On the SV06 Plus, your screen will not work if you install Klipper. You can get it working again via the instructions found [here](https://github.com/fryc88/klipper-sv06plus-screen). - Read this documentation _fully!_ - Make sure your printer is in good physical condition, because print and travel speeds will be _a lot faster_ than they were before. Consider yourself warned. - Follow the steps in order. - If an error was reported at a step, do no proceed to the next step. - It is assumed that you are connected to your host Raspberry Pi (or other host device) via SSH, and that your printer motherboard is connected to the host via a data USB cable. Note that most of the micro USB cables that you find at home are _unlikely_ to be data cables, and it's not possible to tell just by looking. - It is also assumed that the username on the host device is `pi`. If that is not the case, you will have to manually edit `moonraker.conf` and `cfgs/misc-macros.cfg` and change any mentions of `/home/pi` to `/home/yourUserName`. - Klipper _must_ be installed on the host Raspberry Pi for everything to work. Easiest is to use a [~~FluiddPI~~](https://docs.fluidd.xyz/installation/fluiddpi#download) (⚠️ `FluiddPI` is not under active maintenance) or [MainsailOS](https://github.com/mainsail-crew/mainsail/releases/latest) image. Alternatively, you can install `Fluidd` or `Mainsail` via [KIAUH](https://github.com/th33xitus/kiauh). - Robert Redford's performance in _Spy Game (2001)_ was superb! - It is assumed that there is one instance of Klipper installed. If you have multiple instances of Klipper installed, via `KIAUH` for example, then this guide is not for you. You can still use all the configs of course, but the steps in this guide will likely not work for you. - Your question has probably been answered already, but if it hasn't, please post in the [Discussion](https://github.com/bassamanator/Sovol-SV06-firmware/discussions) section. - I would recommend searching for the word `NOTE` in this repository. There are roughly half a dozen short points amongst the various files that you should be aware of if you're using this configuration. ## Flash Firmware 💡 _If you have already flashed klipper onto your motherboard in the past, you can skip this step._ 💡 For the sake of simplicity, I will refer to the klipper firmware file as `klipper.bin` even though the actual filename is something along the lines of `klipper-v0.11.0-148-g52f4e20c.bin`. 💡 The firmware file is located in the `misc` folder. ### Prepare the microSD Card for Flashing ⚠️ Many users have reported having issues flashing Klipper using the Sovol microSD card. - Size: `8GB`. According to Sovol, the largest size that you can use is `16GB`. - File system: `FAT32`. - Allocation unit size: `4096 bytes`. - Must not contain any files _except_ the firmware file. ### Flashing Procedure 1. Disconnect any USB cables that might be connected to the motherboard. 2. Copy `klipper.bin` to the microSD card. 3. Make sure the printer is off. 4. Insert the microSD card into printer. 5. Turn on the printer and wait a minute (usually takes 10 seconds). 6. Turn off the printer and remove the microSD. You may find this [video](https://youtu.be/p6l253OJa34) useful. ⚠️ **Caveat**: Flashing will only work if current firmware filename is _different from previous flashing procedure_. The `.bin` is also important. ## Download Klipper Configuration You can choose _either_ of the 2 following methods. ### Method 1: Clone the Repository 1. `cd ~/printer_data/config` 2. Empty entire `~/printer_data/config` folder. Unfortunately, for safety reasons I will not post this command here. However, in linux, you can delete files via `rm filename`. 3. `git clone -b sv06-plus --single-branch https://github.com/bassamanator/Sovol-SV06-firmware.git .` 💡 Don't miss the period! ### Method 2: Download the ZIP 1. [Download](https://github.com/bassamanator/Sovol-SV06-firmware/archive/refs/heads/sv06-plus.zip) the `ZIP` file containing the Klipper configuration. 2. See `Step 2` in `Method 1`. 3. The parent folder in the `ZIP` is `Sovol-SV06-firmware-sv06-plus`. This is relevant in the next step. 4. Extract **only** the _contents_ of the parent folder into `~/printer_data/config`. ## Initial Steps ### Step 1 1. Find what port the `mcu` (printer motherboard) is connected to via `ls -l /dev/serial/by-id/` or `ls -l /dev/serial/by-path/`. 1. The output will be something along the lines of `lrwxrwxrwx 13 root root 22 Apr 11:10 usb-1a86_USB2.0-Serial-if00-port0 -> ../../ttyUSB0`. 2. `usb-1a86_USB2.0-Serial-if00-port0` is the relevant part. 3. Therefore, the full path to your `mcu` is either `/dev/serial/by-id/usb-1a86_USB2.0-Serial-if00-port0` or `/dev/serial/by-path/usb-1a86_USB2.0-Serial-if00-port0`, depending on the command you used to find the `mcu`. 2. Adjust the `[mcu]` section in `printer.cfg` accordingly. This is just an _example_ `mcu` section: ``` [mcu] serial: /dev/serial/by-id/usb-1a86_USB2.0-Serial-if00-port0 restart_method: command ``` ### Step 2 ❗☠️ **Your finger should be on the power switch for most of these steps** ☠️❗ ❗☠️ **Power off if there is a collision/problem** ☠️❗ 💡 I recommend no filament be loaded for any of these steps. 💡 Find explanations for gcode commands at [https://marlinfw.org/](https://marlinfw.org/) and [klipper.org](https://www.klipper3d.org/G-Codes.html). You will be pasting/typing these commands into the Mainsail/Fluidd console. 1. `G28` 1. Check to see if `X` and `Y` max positions (`G90`, `G1 X300 F3000`, `G1 Y300 F3000`) can be reached, and adjust `position_max`, if necessary. Note, you might be able to go even further. 2. Do a `G34`; mechanical gantry calibration. After the controlled collision against the beam at the top, there will be a 10 second pause for you to verify that both sides of the gantry are pressed up against the `stoppers` at the top. ~~You will hear a succession of beeps.~~ 1. Figure out your `Z` `position_max` by baby stepping your way up to the beam (`G90`, `G1 Z330 F900`, then move up mm by mm). Adjust `position_max`, if necessary. 3. Pid tune the bed, but first move the printhead to the center. Ideally, all Pid tuning should occur at the temperatures that you print most at. 1. `G28` 2. `G90` 3. `G1 X150 Y150 Z40 F6000` 4. `PID_CALIBRATE HEATER=heater_bed TARGET=70` 5. `SAVE_CONFIG` (once completed) 4. Pid tune the extruder while part cooling fan runs at 25%. 1. `G28` 2. `G90` 3. `G1 X150 Y150 Z10 F6000` 4. `M106 S64` 5. `PID_CALIBRATE HEATER=extruder TARGET=245` 6. `SAVE_CONFIG` (once completed) 5. Adjust `z_offset`. Make sure your nozzle if very clean. Do the [Paper test](https://www.klipper3d.org/Bed_Level.html?h=probe_calibrate#the-paper-test). 1. `SET_HEATER_TEMPERATURE HEATER=heater_bed TARGET=60` 2. `SET_HEATER_TEMPERATURE HEATER=extruder TARGET=180` 3. Proceed to next steps after both temperatures have been reached. 4. `G28` 5. `PROBE_CALIBRATE` 6. `SAVE_CONFIG` (once completed) 6. Create a bed mesh. 1. `SET_HEATER_TEMPERATURE HEATER=heater_bed TARGET=60` 2. `SET_HEATER_TEMPERATURE HEATER=extruder TARGET=180` 3. Proceed to next steps after both temperatures have been reached. 4. `G28` 5. `BED_MESH_CALIBRATE` 6. `SAVE_CONFIG` (once completed) If you've made it here, then your printer has been Klipperized, and is ready to print! But first, adjust your slicer. ## Adjust Your Slicer You need to adjust the start and end gcode in your slicer. The relevant macros are `PRINT_START` and `PRINT_END`. Find instructions [here](https://ellis3dp.com/Print-Tuning-Guide/articles/passing_slicer_variables.html#slicer-start-g-code). If you would like to print a purge line before your print starts, at the end of your start gcode, on a new line add `PURGE_LINE`. Here's an example: ``` PRINT_START BED=[first_layer_bed_temperature] HOTEND={first_layer_temperature[initial_extruder]+extruder_temperature_offset[initial_extruder]} CHAMBER=[chamber_temperature] PURGE_LINE ``` ## Directory Structure This repository contains many files and folders. Some are _necessary_ for this Klipper configuration to work, others are not. - **Necessary** items are marked with a ✅. - Items that can _optionally_ be deleted are marked with a ❌. ``` ├── cfgs ✅ │   ├── adxl-direct.cfg │   ├── adxl-rp2040.cfg │   ├── adxl-rpi-pico-2x.cfg │   ├── MECHANICAL_GANTRY_CALIBRATION.cfg │   ├── misc-macros.cfg │   ├── PARKING.cfg │   └── TEST_SPEED.cfg ├── CODE_OF_CONDUCT.md ❌ ├── CONTRIBUTING.md ❌ ├── images ❌ │   ├── cup-border.png │   ├── githubstar.gif │   ├── heart.gif │   ├── logo_white_stroke.png │   └── party_blob.gif ├── misc ❌ │   ├── klipper-v0.11.0-148-g52f4e20c.bin │   ├── M503-output.yml │   ├── M503-plus-output.yml │   ├── SuperSlicer_config_bundle.ini │   ├── sv06-buildPlate.png │   ├── SV06Plus-buildPlate.stl │   ├── SV06-PLUSfirmware-2.23.rar │   └── SV06-texture.svg ├── moonraker.conf ✅ ├── printer.cfg ✅ └── README.md ❌ ``` ## Ko-fi Support Me Ko-fi If you found my work useful, please consider buying me a [Ko-fi](https://ko-fi.com/bassamanator). ## FAQ ##### How do I import a SuperSlicer configuration bundle (`SuperSlicer_config_bundle.ini`) into SuperSlicer? Please see [this discussion](https://github.com/bassamanator/Sovol-SV06-firmware/discussions/13). ##### How do I print using SuperSlicer? Please see [this discussion](https://github.com/bassamanator/Sovol-SV06-firmware/discussions/14). ##### When does beeping occur? 💡 Beeping will likely not work on the SV06 Plus. I recommend not turning it on. The printer will beep upon: - Filament runout. - Filament change/`M600`. - Upon `PRINT_END`. - `MECHANICAL_GANTRY_CALIBRATION`/`G34`. ##### How do I disable beeping? Make the following changes according to your needs. All beeping will be disabled _except_ during gantry calibration. | File | `cfgs/misc-macros.cfg` | | --------------- | -------------------------- | | Section | `[gcode_macro _globals]` | | Variable | `variable_beeping_enabled` | | Disable beeping | `0` | | Enable beeping | `1` | ##### I want to use a filament sensor. How do I set it up? You can find information about the physical setup [here](https://github.com/bassamanator/everything-sovol-sv06#filament-sensor). ##### I have a simple filament sensor connected. How do I enable/disable it? Make the following changes according to your needs. | File | `cfgs/misc-macros.cfg` | | -------------- | ---------------------------------- | | Section | `[gcode_macro _globals]` | | Variable | `variable_filament_sensor_enabled` | | Disable sensor | `0` | | Enable sensor | `1` | ##### My filament runout sensor works, but I just started a print without any filament loaded. What gives? A simple runout sensor can only detect a change in state. So, if you start a print without filament loaded, the printer will not know that there is no filament loaded. You should test your sensor by having filament loaded, starting a print, then cutting the filament. The expected behaviour is that the print will pause, and as long as you have beeping enabled, you will hear 3 annoying beeps. ##### What happens when I put in `M600`/colour change at a certain layer? 1. The printer will beep 3 times (not annoyingly). 2. Printing will stop. 3. The printhead will park itself front center. 4. The hotend will turn off, but the bed will remain hot. ##### What happens when I pause a print? Same behaviour as `M600`/colour change _except_ there won't be any beeping. ##### What happens when filament runs out? _If_ you have a working filament sensor, the same behaviour as `M600`/colour change will occur _except_ the beeps will be fairly annoying. ##### How do I resume a print after a colour change or filament runout? ⚠️ _Do not disable the stepper motors during this process!_ The printhead is now parked front center waiting for you to insert filament. You will: 1. Heat up the hotend to the desired temperature. - Use your Klipper dashboard. 2. Purge (push) some filament through the nozzle. - Use your Klipper dashboard, and extrude maybe 50mm (for a colour change you probably want to extrude more). - OR, you can push some filament by hand _making sure to first disengage the extruder's spring loaded arm_. 3. Hit resume in your Klipper dashboard. ## Useful Resources - [Everything Sovol SV06](https://github.com/bassamanator/everything-sovol-sv06) - [RP2040-Zero ADXL345 Connection Klipper](https://github.com/bassamanator/rp2040-zero-adxl345-klipper) - ⭐⭐⭐⭐⭐ [Ellis' Print Tuning Guide](https://ellis3dp.com/Print-Tuning-Guide) - [Simplify3D Print Quality Troubleshooting Guide](https://www.simplify3d.com/resources/print-quality-troubleshooting/) ## Links - [SV06 Official Marlin Source Code](https://github.com/Sovol3d/Sv06-Source-Code) - [SV06 Official Models](https://github.com/Sovol3d/SV06-Fully-Open-Source) - [SV06 Plus Official Marlin Source Code and Models](https://github.com/Sovol3d/SV06-PLUS) ## Sources - https://www.klipper3d.org - https://ellis3dp.com/Print-Tuning-Guide - https://github.com/strayr/strayr-k-macros - https://docs.vorondesign.com/build/software/miniE3_v20_klipper.html - https://github.com/spinixguy/Sovol-SV06-firmware - https://www.printables.com/model/378915-sovol-sv06-buildplate-texture-and-model-for-prusas - https://github.com/AndrewEllis93/Ellis-SuperSlicer-Profiles - https://www.printables.com/model/447787-sovol-sv06-plus-build-plate [![ko-fi](https://ko-fi.com/img/githubbutton_sm.svg)](https://ko-fi.com/H2H0HIHTH)
